Cummins 6BT5.9-G2
Price excl. GST
Print
INFO
Product Group
Engines
Brand / model
Cummins 6BT5.9-G2
Manufacture date (yr)
2018
Condition
New/unused
Location
Jining, Shandong, China
Country
China
General grade
1
2
3
4
5
Mascus ID
32661D37
PRICE
Select currency
ITEM DETAILS
Internal stock no.
6BT5.9-G2
Latest Date of Inspection
yes
Power Output
86 kW (117 hp)
Part ID
6BT5.9-G2
Full log books
Yes
Manufacturing / Serial number
6BT5.9-G2
Transport weight
480 kg
Transport dimensions (LxWxH)
1300 x 900 x 1400 mm
RPM
1500
Emission level
Stage II / Tier II
Condition info/guarantee
ISO9001
Production country
China
Delivery terms
FCA, CPT, FOB, CFR, CIF, EXW
Additional Info
Cummins 6BT5.9-G2 Generator Engine
General Information
Engine Model 6BT5.9-G2
Engine Type 6 Cylinders, in Line
Displacement 5.9 L
Bore*Stroke(mm) 102 * 120
CPL Number 1189-02
Net Weight (with flywleel & alternator) 411Kg
Overall Diemension(L*W*H) 1110mm*750mm*988mm
Technical Specification
Fuel System Wuxi Weifu A Pump/GAC Electronic Governor
Aspiration Turbocharged
Governing Rate ≤1%
Electrical System(Starter Motor/Alternator) 12V/24V
Lowest Starting Temp without auxiliary system -12℃
Engine Cooling Fluid Volume 9.9 L
Performance Data
Rated Power/Speed 86 kW/115HP @ 1500rpm
Torque @ Rated Power 548 N.m @ 1500 rpm
Standby Power/Speed 92 kW/123HP @ 1500rpm
Torque @ Standby Power 586 N.m @ 1500 rpm
Fuel Consumption @ Rated Power 214g/Kw.h
Fuel Consumption @ Standby Power 221g/Kw.h
Idel Speed 950 – 1050 rpm
