Amount of previous owners
1
Latest Date of Inspection
2
Transport dimensions (LxWxH)
870 m
Condition info/guarantee
2
Additional Info
Features:
13-14Hp branded engines, Honda, Mitsubishi, and Kohler
No windings rotor and brushless stator
ECO running with auto-idle devices;
Strong arc force for easy burning electrode;
Polarity easy switched with DINSE type plug;
High OCV 75V
Robust engineering tube frame
FREE 25% EXTRA POWER
13HP for 240 Amp & 3KW; 85KG, 0.23CBM
BRUSHLESS, DIRECT COUPLING
Specifications given herein are subject to change without notice
CAT. NO. DUV13-20170520
PRINTED IN 2017
KOVO ENGINE DRIVEN WELDER EW240G
DC Welder
Driven - Direct Coupling
Rated Output KW 6.3
Rated Current DCA 220-CC
Rated Voltage DCV 28.8
Current Range DCA 30-240
OCV DCV 80
Duty Cycle % 60
Type - Rectified DC output type
Applicable Electrode mm 2.0-5.0
Aux. Power
Rated Output KW 3
Rated Voltage V 120V/220V/240V
Phase - Single
Power Factor % 100
Rate - Continuous
ENGINE
Model - HONDA GX390 (MITSUBISHI or KOHLER)
Type - 4-stroke, air cooled
Cylinder arrangement - Single cylinder
Total displacement cc 389
Rated Output KW 9.6
Speed rpm 3,600
Fuel Gasoline
Start System - Recoil or Electric
OTHER
Fuel Tank Capacity L 6.5 or 17L
Battery Capacity - 12V-26AH
Dimension (L×W×H) mm 750×545×600
Net Dry Mass Kg 85Show more
