Sany STC 250
Price excl. GST
Print
INFO
Product Group
All terrain cranes
Brand / model
Sany STC 250
Manufacture date (yr)
2022
Country
China
General grade
1
2
3
4
5
Mascus ID
F168571F
PRICE
Select currency
ITEM DETAILS
Latest Date of Inspection
2025-09-11
Amount of previous owners
1
Gross Weight
29,000 kg
Maximum lift capacity
25 ton
Max lifting capacity at end of jib
20 ton
Emission level
Stage V / Tier V
Boom length
41 m
Jib length of crane
57 m
Maximum lift height
50 m
Crane type
Hydraulic jib
Original colour
Orginal
Engine manufacturer
Orginal
Carrier type
Wheeled
Condition info/guarantee
1 Year
Front tyres remaining
98
Rear tyres remaining
2
Production country
China
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Accessories
Hook blocks
Additional Info
起重性能参数:
最大起重量:25t
最大起升高度:52.5m
最大起重力矩:1266kN·m
主卷扬最大单绳速度:135m/min
尺寸参数:
整机全长:13620mm
整机全宽:2550mm
整机全高:3500mm
支腿跨距(横 × 纵):6.4×5.5m
重量参数:
整机总重量:34200kg
最大配重:7t
动力参数:
发动机型号:潍柴 WP8.320E62
发动机最大功率:235kW/2100rpm
发动机最大输出扭矩:1300N·m/(1200-1700)rpm
行驶参数:
最高行驶速度:90km/h
最小转弯半径:10.5m
最大爬坡度:45%
接近角:11°
离去角:12°
工作速度参数:
起重臂全伸 / 缩时间:80/100s
起重臂全起 / 落时间:40/50s
最大回转速度:2.5r/min
