CAT 320 GC
Price excl. GST
Print
INFO
Product Group
Crawler excavators
Brand / model
CAT 320 GC
Manufacture date (yr)
2019
Country
China
General grade
1
2
3
4
5
Mascus ID
2E0066EA
PRICE
Select currency
ITEM DETAILS
Power type
Diesel
Latest Date of Inspection
2024-04-29
Undercarriage condition
good condition
Engine
Cat C4.4 ACERT
Gross Weight
20,500 kg
Power Output
110 kW (150 hp)
Engine manufacturer
Cat
Emission level
Stage IV / Tier IV final
Bucket capacity
1 m3
Track width
600 mm
Transport dimensions (LxWxH)
9.53/3.17/2.96 m
Original colour
yellow
Condition info/guarantee
good condition
Production country
United States
Delivery terms
FCA, FAS, FOB, EXW
Certificates
EPA, CE, ANSI, AS, CSA
Additional Info
Main Performances:
·Travelling speed(km/h):5.9
·Rotating speed(r/min):11.3
·Digging force of bucket(kN):129
·Digging force of arm(kN):99
Working Range:
·The maximum excavating height(mm):9440
·The maximum unloading height(mm):6580
·The maximum excavating depth(mm):6630
·The maximum excavating radius(mm):9770
·The maximum vertical excavating depth(mm):6010
Boundary Dimension:
·Boom length(mm):6370
·Arm length(mm):4200
·Track length(mm):8108
·The minimum rotation radius of the rear end(mm):2830
·The minimum ground clearance(mm):470
Oil Capacity:
·Fuel tank volume(L):345
·Hydraulic oil tank volume(L):115
·Engine oil capacity(L):15
